Model No	OTM-W100-36-F
Input Voltage	100-277V AC
Input Current	1.44A
Input Frequency	50-60 Hz
Output Voltage	36V DC
Output Current	2.8A
Wattage	100W
Dimmable	Yes (0-10 Dimming)
IP Rating	IP67 (Dry, Damp, and Wet Locations)
Dimensions	362 x 75 x 57.6mm (14.25 x 2.95 x 2.26in)
Ambient Temperature(Ta)	40℃
Case Temperature(Tc)	85℃
Certifications



Features:

• Constant voltage LED driver designed for 0-10V dimming applications
• Input voltage range of 100-277V AC for compatibility with various electrical systems
• Input current of 1.44A at a frequency of 50-60 Hz
• Output voltage of 36V DC with a maximum output current of 2.8A
• Wattage rating of 100W for efficient power supply to LED lights
• Dimmable with 0-10V dimming control for adjustable brightness levels
• IP67 rating for protection against dust, water, and environmental conditions
• Compact dimensions of 362 x 78.7 x 57.6mm (14.25 x 3.1 x 2.26in) for easy installation
• Ambient temperature rating of 40℃ for reliable performance
• Case temperature rating of 85℃ for safe operation
• UL and E certified for compliance with safety standards in the United States and Canada.
