Model No	OTM-W60-48-F
Input Voltage	100-277V AC
Input Current	0.86A
Input Frequency	50-60 Hz
Output Voltage	48V DC
Output Current	1.25A
Wattage	60W
Dimmable	Yes (0-10 Dimming)
IP Rating	IP67 (Dry, Damp, and Wet Locations)
Dimensions	333 x 75.25 x 56.81mm(13.12 x 2.96 x 2.23in)
Ambient Temperature(Ta)	40℃
Case Temperature(Tc)	85℃
Certifications



Features:

• 60W LED driver with constant voltage output of 48V DC
• Output current of 1.25A for efficient power supply to LED lights
• 0-10V dimming function for precise control of brightness levels
• Wide input voltage range of 100-277V AC for compatibility with various electrical systems
• Input current of 0.86A at a frequency of 50-60 Hz
• IP67 rating for protection against dust, water, and other environmental factors
• Compact dimensions of 333 x 78.31 x 56.81mm (13.12 x 3.1 x 2.23in)
• Operating ambient temperature rating of 40℃ for reliable performance
• Maximum allowable case temperature of 85℃ for safe operation
• UL and CE certified for compliance with safety and performance standards
• Suitable for indoor and outdoor lighting applications, architectural lighting, and commercial lighting.
